Basic specifications

Electrical lifespan:2A/12VDC, 40T85, 100000 cycles
2A/24VDC, 40T85, 50000 cycles
10mA/12VDC, 40T85, 250000 cycles
0.1mA/250VAC, 40T85, 50000 cycles
0.5mA/250VAC, 40T85, 10000 cycles

Mechanical lifespan:1,000,000 cycles

Electric shock resistance:50mΩ max. (initial)

Insulation resistance:100 MΩ min.

Electrical strength:500VAC for 60 +/- 5 sec

Shell:UL94 V-0

Operating Temperature:

Operating force:

Contact point:

Minimum packaging quantity:

Minimum order quantity:

Common applications:Home appliances, robots, automation equipment and production lines, office automation equipment, electric tailgate signal switches, hood lock switches, door information switches, door handles, charging guns, etc
